Product Name Rated Voltage
DC (V)		 Rated
Current (A)		 Breaking
Capacity (A)		 Typical Cold.
Resistance (mOhms)		 Typical Voltage
Drop (mV)		 Typical Pre-Arcing
I2t (A2Sec)		 Data Sheet
12 100.15 32 15 50 3.8 75 63
12 100.20 32 1 50 2.9 70 82
12 100.25 32 25 50 1.6 60 90
12 100.30 32 30 50 1.3 60 100
12 100.12 32 12 50 5.9 85 47
12 100.10 32 10 50 7.0 90 32
12 100.8 32 8 50 8.0 100 20
12 100.7 32 7 50 11.5 120 19
12 100.6 32 6 50 15.5 140 14
12 100.5 32 5 50 22 135 7
12 100.4.5 32 4.5 50 28 150 4.5
12 100.4 72 4 50 33 160 3.3
12 100.3.5 72 3.5 50 37 175 2.8
12 100.3 72 3 50 49 185 2.4
12 100.2.5 72 2.5 50 79 230 1.9
12 100.2 72 2 50 133 310 1.2
12 100.1.5 72 1.5 50 230 367 0.17
12 100.1 72 1 50 485 550 0.2
12 100.0.75 72 0.75 50 775 680 0.15
12 100.0.5 72 0.5 50 1050 690 0.0019
12 100.0.375 72 0.375 50 1850 720 0.00077
12 100.0.25 72 0.25 50 3700 1350 0.00038
