| Product Name | Rated Voltage DC (V) |
Rated Current (A) |
Breaking Capacity (A) |
Typical Cold. Resistance (mOhms) |
Typical Voltage Drop (mV) |
Typical Pre-Arcing I2t (A2Sec) |
Data Sheet |
|---|---|---|---|---|---|---|---|
06 100.1
|
63 | 1 | 50 | 240 | 310 | 0.035 |
|
06 100.0.25
|
63 | 0.25 | 50 | 3100 | 1435 | 0.0012 |
|
06 100.0.75
|
63 | 0.75 | 50 | 440 | 550 | 0.015 |
|
06 100.0.5
|
63 | 0.5 | 50 | 1000 | 750 | 0.005 |
|
06 100.0.375
|
63 | 0.375 | 50 | 1600 | 1250 | 0.0028 |
|
06 100.1.5
|
63 | 1.5 | 50 | 125 | 250 | 0.08 |
|
06 100.2
|
63 | 2 | 50 | 68 | 17 | 0.16 |
|
06 100.2.5
|
63 | 2.5 | 52 | 52 | 200 | 0.29 |
|
06 100.3
|
63 | 3 | 50 | 34 | 155 | 0.32 |
|
06 100.3.5
|
32 | 3.5 | 50 | 22 | 130 | 0.54 |
|
06 100.4
|
32 | 4 | 50 | 20 | 100 | 0.95 |
|
06 100.5
|
32 | 5 | 50 | 13 | 95 | 1.80 |
|
06 100.6
|
32 | 6 | 50 | 8.5 | 80 | 2.9 |
|
06 100.7
|
32 | 7 | 50 | 6.5 | 80 | 3.5 |
|
06 100.8
|
32 | 8 | 50 | 5.3 | 75 | 4.8 |
|
